TIDEMASTER Hunter 28
Stable, Unsinkable, Energy-Efficient
TECHNICAL SPECIFICATIONS
Length Overall
8.7 m
Beam
2.5 m
Draft
0.4 m
Material
Aluminum Alloy 5083-H116
Aluminum Alloy 5052-H32
Maximum Power
Twin 225 HP
（450 HP Total）
Bottom Plate
6 mm
Side Plate
4 mm
Fuel Capacity
400 L
Transom Plate
7-9 mm
Fresh Water
100 L
Dry Weight
1,750 kg
Maximum Capacity
8 persons
STANDARD CONFIGURATIONS
HULL & STRUCTURE
- Aluminum alloy 5083-H116 Hull (0AED)
- Longitudinal and transverse stringer system (0AED)
- AkzoNobel® AWLGRIP solid color exterior paint (0AED)
- 2 coats epoxy primer + 3 coats anti-fouling paint (0AED)
- Four 316 stainless steel cleats with back plates (0AED)
- FRP composite hardtop - vacuum-infused, PVC foam core (0AED)
- Stainless steel anchor with 100' rode (8mm chain) (0AED)
- Bow tow U-Hook (0AED)
DECK FEATURES
- Adjustable helm seats with non-water-absorbing foam cushions (0AED)
- Fold-down rear seats (0AED)
- PVC synthetic teak decks (0AED)
- Hull-side storage bays (0AED)
- Main deck storage lockers (0AED)
- Foredeck anchor locker (0AED)
- Live bait tank with cutting board (0AED)
- Self-draining deck system (0AED)
- LED step lights (0AED)
- Retractable swim ladder (0AED)
- Rocket launcher with 7 rod racks (0AED)
ELECTRICAL SYSTEM
- 12V DC + 120V/60Hz AC via inverter system (0AED)
- Two 12V/200AH deep-cycle batteries (0AED)
- JMT® 40A DC charger + 3000W AC inverter (0AED)
- LED lighting throughout (0AED)
- AQUA SIGNAL® navigation lights (0AED)
- Remote searchlight (0AED)
- 50-amp shore power connection (0AED)
MECHANICAL SYSTEMS
- 12V DC blowers for bilge and head ventilation (0AED)
- Fresh water pump system (0AED)
- Waste discharge pump (0AED)
- 2000gph bilge pump + emergency manual pump (0AED)
- TACMA® electric marine head (0AED)
- UFLRX® steering system (0AED)
- 103 gal aluminum fuel tank with gauges (0AED)
- 26 gal aluminum holding tank with deck pump-out (0AED)
- 5-year transferable hull structure warranty (0AED)
- 1-year limited warranty on 3rd-party equipment (0AED)
